AUSLAND CNC200 PRO INJECTOR CLEANER TECHNICAL PARAMETER
Dimensions: 545mm(L)* 495mm(W)* 565mm(H)
Weight: 19kg
Test cylinder: 2 (max)
Test tube capacity: 120cc
Fuel tank capacity: 2.2L
Rotate speed：0-9975r/min, step: 25r/min
Pulse width: 0-30ms, step:0.1ms
Count: 0-9975r, step: 25r
Time: 0-9975s, step: 5s
System pressure: 0-6.2kg/cm²(variable regulated)
System flow: 4L/min
Ultrasonic wave frequency: 40KHz
Ultrasonic wave power: 100W
CNC200 PRO INJECTOR CLEANER FUNCTION:
1.To test injector resitance ( one by one ), and display the data ( NEW ).
2.Use PWM ( pulse width modulation ) to control and adjust fuel pressure( NEW ).
3.The special software for motorcycle injector ( NEW ).
4.To test the injecting angle and atomizing, to test the injector dribbling, to test the injector uniformity.
5.To test conduct the physical and chemical cleaning of the blocked or trouble injector, ultrasonic cleaning , test cleaning and on-vehicle cleaning.
6.To test and analyze the injector of operating mode and quality.
7.Can clean the Motorcycle engine without dismantling ( choose matched connector).
8.Can operate the auto static test, dynamic test and selective test with the injecting dribbling, angles, atomization, uniformity of one or more(1-2) injectors, can simulate any state of the vehicle to observe the complete process of injectors.Engine RPM
